FANUC Series 16i/18i Additional Manual Page 13
Additional Manual
- Not Allowed functions
The hypothetical linear axis control function cannot be used with the following
functions.
- Flexible synchronous control
- Angular axis control
- Chopping function
- Function for hobbing machine
- Simple electric gear box
- AI contour control
- AI nano contour control
- AI high precision contour control
- AI nano high precision contour control
3)
- Advanced preview control
- Manual reference point return
2
)
2
)
2
)
2
)
2
)
2
)
2
)
2
)
2
)
2
)
2
)
The real axis command mode should be selected for the manual reference point
return mode. Manual reference point return cannot be executed for the hypothetical
axes.
During the hypothetical axis command mode, the manual reference point return
operation for the hypothetical axes and also for the real axes in the hypothetical plane
are ignored.
When all real axes in the hypothetical plane are completed to establish the reference
position, all hypothetical axes in the hypothetical plane are also completed to
establish the reference position.
If the only one real axis in hypothetical plane loses the reference position, all
hypothetical axes in the hypothetical plane also lose the reference position.
NOTE
The alarm (P/S5359) is generated at selecting the hypothetical axis
command mode until the reference positions are established on all
real axes and hypothetical axes in the hypothetical plane.
However, if all real axes in the hypothetical plane have the absolute
position detector, the hypothetical axis command mode can be
selected from power on.
2
)
2
)
2
)
2
)
2
)
2
)
- Stored stroke check 1
The stored stroke check 1 is executed on both hypothetical axes (X,Y) and real axes
(V,C,Z). The stroke check for the hypothetical axes is executed based on the
hypothetical machine coordinate value.
3)
The parameter BFA (No.1300#7) is available for the hypothetical axes and real axes.
A-79306E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i /18i –MB, 18i-MB5
Hypothetical linear axis control
Specifications
Dec.11.2003
T.Horie H.Kouzai
13
/25
02
Jan.30.2004
N.Aizawa
A
dd or Change at 2) part H.Kouzai
A
dd or Change at 3) part H.Kouzai
N.Aizawa
Dec.20.2004
03
