FANUC Series 16i/18i Additional Manual Page 25
Additional Manual
5 Alarm and Message
Number Message Contents
P/S5356 IMPROPER G-CODE
Illegal command was commanded in the hypothetical axis
command mode or in the real axis command mode.
P/S5357 ILLEGAL AXIS SELECT The real axes is commanded in the hypothetical axis
commanded mode.
The hypothetical axis is commanded in the real axis command
mode.
P/S5359 MODE CHANGE ERROR This alarm is generated at following cases.
1. Mode switching was executed without using non buffering M
code in automatic operation.
2. Mode was switched to the hypothetical axis command mode
in case that the only one axis in the hypothetical plane loses
the reference position.
3. Mode was switched in case the parameter LRP (No.1401#1)
is set to “0”.
4. Mode switching was executed during the following mode.
- Cutter radius compensation
- Tool length compensation
- Tool offset
- Scaling
- Programmable mirror image
- Coordinate system rotation
- Canned cycle
5. During the hypothetical axis command mode, any axes in
the hypothetical plane lose the reference position.
P/S000 PLEASE TURN OFF POWER During the hypothetical axis command mode, any axes in the
hypothetical plane lose the reference position.
