FANUC Series 16i/18i Additional Manual Page 24

Additional Manual
1022 Setting of each axis in the basic coordinate system
[Data type] Byte axis
To determine the following planes used for circular interpolation, cutter compensation
C, etc., each control axis is set to one of the basic three axes X,Y and Z, or an axis
parallel to the X,Y, or Z axis.
G17 : Plane Xp-Yp
G18 : Plane Zp-Xp
G19 : Plane Yp-Zp
Only one axis can be set for each of the three basic axes X,Y and Z, but two or more
parallel axes can be set.
Set value Meaning
0 Neither the basic three axes nor a parallel axis
1 X axis of the basic three axes
2 Y axis of the basic three axes
3 Z axis of the basic three axes
5 Axis parallel to the X axis
6 Axis parallel to the Y axis
7 Axis parallel to the Z axis
The hypothetical axis must be set as one of the basic three axes.
The real linear axis in the hypothetical plane must be set as the parallel axis to the
corresponding hypothetical axis.
This parameter for the real rotary axis in the hypothetical plane must be set to “0”.
1023 Number of the servo axis for each axis
[Data type] Byte axis
[Valid data range] 0,1 to Number of controlled axes
This parameter for the hypothetical axes must be set to “-128” for defining
hypothetical axes as dummy axis
