FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 10
Additional Manual
A-90078E
Execution of Path Table
Parameter PCA (No.11104#0) doesn't influence End of contour control (R30).
Path Table Operation in Multi-path (head)
Parameter PCA (No.11104#0) changes the position command of whole paths
(heads).
Override
Parameter PCA (No.11104#0) doesn't influence Override.
Parameters
#7 #6 #5 #4 #3 #2 #1 #0
11104 PCA
[Data Type] Bit
PCA During Path Table Operation, the position command is
0: the value of machine coordinate. (The unit is the unit of workpiece
coordinate.)
1: the value of workpiece coordinate.
Alarms
Alarm
No
Message Meanings
PS0441 DUPLICATE PATH TABLE The same Path Table numbers exist.
Example)
Both <SPDL_TABLE_1234_X1> and
<TIME_TABLE_1234_X1> exist.
PS0442
PATH TABLE COMMAND
EXCES ERR
1. At the start of the Path Table Operation, the
difference between the actual axis position and the
start command at the Path Table exceeds the
parameter No.11101.
2. At the start of the Path Table Operation, the
difference between the actual spindle speed and the
start command of spindle speed at the Path Table
exceeds the parameter No.11102.
PS0443 PTRDY SIGNAL IS OFF Even though the Path Table Ready signal
PTRDY<Fn519#6> is "0", the Path Table Operation is
triggered.
Sheet
Title
Draw
No.
FANUC Series 30i/31i
Specifications of Path Table Operation
Workpiece coordinate command
FANUC LTD
10/17
Ed. Date Design Description
Date Jun.06.’5 Desig. T.Watanabe Apprv. Y.Takeuchi
Contents Summary of FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual
