FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 11
Additional Manual
A-90078E
Alarm
No
Message Meanings
PS0444 ILLEGAL PATH TABLE
M-CODE
M/P/Q-code for starting the Path Table operation is
not correct.
PS0451 ILLEGAL AUXILIARY
FUNCTION TABLE COMMAND
When M code is output, the ladder of the PMC does
not execute the completion processing of the previous
M code.
PS0452 ILLEGAL PATH TABLE
OPERATION
In Path Table Operation, the following problems
occurred.
Skip command is not correct.
The connection of the Path Table is not correct.
Other Path Table Operation is not correct.
Detail alarm number 30:
Any error occurred at changing spindle mode.
Detail alarm number 31:
Spindle was not in Cs contour control mode at the
start of Path Table Operation.
Detail alarm number 32:
Contour control command (R1) was commanded to
the spindle that is in speed mode (R11). Please
modify the path table program.
Detail alarm number 33:
The input unit at executing path table operation
was different from the input unit at converting
path table program. Please convert path table
program again.
Detail alarm number 34:
Modal conditions at the start of Path Table
Operation were incorrect. Please modify the NC
(ISO) program.
Detail alarm number 35:
Axis movement command to the angular axis was
specified in case of parameter PCA (No.11104#0)
was 1. Please set the parameter PCA (No.11104#0)
to 1 or modify the NC (ISO) program.
