FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 9
Additional Manual
A-90078E
Alarm No. Meaning
6
One Path Table Operation is started again after interruption even i
f
other Path Table Operations are executing.
7
There is no specified Path Table number in the memory.
8
The Path Table number is duplicated.
9
The Path Table number in case of skip is duplicated.
11
The Path Table number to be connected is duplicated.
12
The Path Table to be connected does not exist.
13
The Path Table in case of skip does not exist.
14
The actual axis position and the axis position at the start of Path
Table differ beyond the limit by the parameter No.11101.
15
The actual spindle position and the spindle position at the start o
f
Path Table differ beyond the limit by the parameter No.11102.
16
The spindle axis for the reference was completed previously.
17
The specification of time reference is not correct.
19
The spindle axis used as the reference is not specified by time
reference.
26
The setting of spindle contouring control is not correct.
27
The rotary axis setting of spindle contouring control is not correct.
29
Too many positions are commanded in the short period.
30
Any error occurred at changing spindle mode.
31
Spindle was not in Cs contour control mode at the start of Path
Table Operation.
32
Contour control command(R1) was commanded to the spindle that is
in speed mode (R11). Please modify the path table program.
33
The input unit at executing path table operation was different from
the input unit at converting path table program. Please convert path
table program again.
34
Modal conditions at the start of Path Table Operation were incorrect.
Please modify the NC(ISO) program.
35
Axis movement command to the angular axis was specified in case
of parameter PCA(No.11104#0) was 1. Please set the parameter
PCA (No.11104#0) to 1 or modify the NC (ISO) program.
Others
Unexpected alarm
