FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 13
Additional Manual
A-90078E
Manual absolute
When manual interrupts during the path table operation block, the axis moves
in the shifted position until the end of path table operation.
Even if manual absolute on (*ABSM=0), the axis moves in the shifted position
until the end of path table operation. The axis returns to the programmed
path at the first absolute command block after the path table operation.
Example)
N10 G00 X0.0 Z0.0 ;
N20 G00 X2.0 Z2.0 ;
N30 M100 Q1111 ;
N40 G00 X2.0 Z5.0 ;
<TIME_TABLE_1111_X>
R98 ;
L0 X1.0 ;
L1000 X1.5 ;
L2000 X2.0 ;
R99 ;
<TIME_TABLE_1111_Z>
R98 ;
L0 X2.0 ;
L1000 X3.0 ;
L2000 X4.0 ;
R99 ;
Sheet
Title
Draw
No.
FANUC Series 30i/31i
Specifications of Path Table Operation
Workpiece coordinate command
FANUC LTD
13/17
Ed. Date Design Description
Date Jun.06.’5 Desig. T.Watanabe Apprv. Y.Takeuchi
Contents Summary of FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual
- Page 1FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece coordinate command GENERAL ··································································································· 2 TABLE HEADER ······················································································
- Page 2General In case that parameter PCA(No.11104#0) is 1, position command becomes the value of workpiece coordinate system during Path Table Operation. In case that parameter PCA(No.11104#0) is 1, position command becomes the value of machine coordinate system during Path Table Operation. Please refer t
- Page 3Data of Axis Motion Table Data of Axis Motion Table memorizes the too axis position corresponding to the reference values such as the time or the spindle position. The data is configured as follows. X2 X-axis Position X1 X3 X0 X4 L0 L1 L2 L3 L4 Reference value Format L_ X_ ; L : Reference Value (Tim
- Page 4Reference Value Parameter PCA(No.11104#0) doesn't influence the reference value. Axis Position The axis position corresponding to the reference value is specified in X-address. The value is radius expression even if the diameter expression is applied in CNC programming. In case that parameter PCA(No
- Page 5Data of Spindle Command Table Please refer to "FANUC Series 30i/31i-A Specifications of Path Table Operation" (A-79645E) in order to know about FORMAT. Reference Value Parameter PCA(No.11104#0) doesn't influence the reference value. Definition R Parameter PCA(No.11104#0) doesn't influence the defini
- Page 6Contouring Control Start of Contouring Control L_ X_ R31 ; The spindle mode is changed to the contouring control mode at the time L_, and the spindle is decelerated and stopped at the position X_. The command is ignored when the spindle is already in contouring control mode (R31). In case that param
- Page 7In case that parameter PCA(No.11104#0) is 0, the position (X_) becomes the value of machine coordinate. Tool compensation quantity is not considered to calculate surface speed. Example) L100 S4000 X2=100.0 R41 ; The spindle control is changed into the constant surface speed control mode. The standar
- Page 8FOCAS2 Window Function Parameter PCA(No.11104#0) doesn't influence the FOCAS2 functions except cnc_rdptaxitablestatus() and cnc_rdptsptablestatus(). cnc_rdptaxitablestatus In case that parameter PCA(No.11104#0) is 1, the following information becomes the value of workpiece coordinate. In case that p
- Page 9Alarm No. Meaning One Path Table Operation is started again after interruption even if 6 other Path Table Operations are executing. 7 There is no specified Path Table number in the memory. 8 The Path Table number is duplicated. 9 The Path Table number in case of skip is duplicated. 11 The Path Table
- Page 10Execution of Path Table Parameter PCA (No.11104#0) doesn't influence End of contour control (R30). Path Table Operation in Multi-path (head) Parameter PCA (No.11104#0) changes the position command of whole paths (heads). Override Parameter PCA (No.11104#0) doesn't influence Override. Parameters #7 #
- Page 11Alarm Message Meanings No PS0444 ILLEGAL PATH TABLE M/P/Q-code for starting the Path Table operation is M-CODE not correct. PS0451 ILLEGAL AUXILIARY When M code is output, the ladder of the PMC does FUNCTION TABLE COMMAND not execute the completion processing of the previous M code. PS0452 ILLEGAL P
- Page 12Note Rotation axis The parameter RAB (No.1008#1) and Rotary axis control are not available during Path Table Operation. The movement direction of the rotation axis follows a command value. Example) In case that rotation axis (A type: parameter ROTx (No.1006#0) is 1 and parameter ROSx (No.1006#1) is
- Page 13Manual absolute When manual interrupts during the path table operation block, the axis moves in the shifted position until the end of path table operation. Even if manual absolute on (*ABSM=0), the axis moves in the shifted position until the end of path table operation. The axis returns to the prog
- Page 14Manual operation interrupts during the NC block before path table operation block: *ABSM
- Page 15Manual operation interrupts during Path Table Operation block: *ABSM
- Page 16Mirror image In case that parameter PCA (No.11104#0) is 1, mirror image is available during Path Table Operation. In case that parameter PCA (No.11104#0) is 0, mirror image is not available during Path Table Operation. Tool geometric compensation In case that parameter PCA (No.11104#0) is 1, tool ge
- Page 17Angular axis control In case that parameter PCA(No.11104#0) is 1, Path Table Operation can move angular axis during angular axis control. In case that parameter PCA(No.11104#0) is 0, Path Table Operation can not move angular axis during angular axis control. P/S alarm No.452 (dist_alm_no=35) will oc
