A termination of servo control cards, of which servo software is 90Ax, for FS16i/18i/21i/15i/160i/180i/210i/150i/160is/180is/210is-Model A Additional Manual Page 4
Additional Manual
2. Servo software and Servo control card
[FS16i/18i/21i/160i/180i/210i/160is/180is/210is-MODEL A]
Item Specification for 90Ax Specification for 90Bx
Digital servo software A02B-0236-H590#90A0 A02B-0236-H590#90B0
Digital servo software A02B-0236-H590#90A3 A02B-0236-H590#90B3
Digital servo software A02B-0236-H590#90A6 A02B-0236-H590#90B0
Digital servo software A02B-0236-H590#90A7 A02B-0236-H590#90B7
Servo control card (2 axes) for mother board
A02B-0236-H015
(A20B-3300-0121)
A02B-0236-H081
(A20B-3300-0243)
Servo control card (4 axes) for mother board
A02B-0236-H016
(A20B-3300-0120)
A02B-0236-H082
(A20B-3300-0242)
Servo control card (6 axes) for mother board
A02B-0236-H017
(A17B-3300-0201)
A02B-0236-H083
(A20B-3300-0241)
Servo control card (8 axes) for mother board
A02B-0236-H018
(A17B-3300-0200)
A02B-0236-H084
(A20B-3300-0240)
Servo control card (Learning control B)
for mother board
A02B-0236-H019
(A17B-3300-0300)
A02B-0236-H087
(A20B-3300-0246)
Servo control card (2 axes) for sub CPU
board
A02B-0236-J075
(A20B-3300-0121)
A02B-0236-J351
(A20B-3300-0243)
Servo control card (4 axes) for sub CPU
board
A02B-0236-J076
(A20B-3300-0120)
A02B-0236-J352
(A20B-3300-0242)
Servo control card (6 axes) for sub CPU
board
A02B-0236-J077
(A17B-3300-0201)
A02B-0236-J353
(A20B-3300-0241)
Servo control card (8 axes) for sub CPU
board
A02B-0236-J078
(A17B-3300-0200)
A02B-0236-J354
(A20B-3300-0240)
Servo control card (Learning control B)
for sub CPU board
A02B-0236-J079
(A17B-3300-0300)
A02B-0236-J357
(A20B-3300-0246)
→
• Specification in the parentheses is PCB specification.
