  2. A termination of servo control cards, of which servo software is 90Ax, for FS16i/18i/21i/15i/160i/180i/210i/150i/160is/180is/210is-Model A

A termination of servo control cards, of which servo software is 90Ax, for FS16i/18i/21i/15i/160i/180i/210i/150i/160is/180is/210is-Model A Additional Manual Page 7

Additional Manual
4. Note
1) If the servo card for the servo software 90Bx is applied to the present 90Ax system, it is
necessary to change the parameter.
[FS16i/18i/21i/160i/180i/210i/160is/180is/210is-MODEL A]
1. If
No.1902#0 = ”1” or 1902#1 = ”1”, please set “40” from No.1970 to No.1979.
(FSSB slave setting)
2. If No.2004 = 00000011, this means that HRV2 function is used, please add “–2048” to a value
of No.2095.
[FS15i/150i-MODEL A]
1. If
No.1090#0 = ”1” or 1090#1 = ”1”, please set “40” from No.1120 to No.1129.
(FSSB slave setting)
2. If No.1809 = 00000011, this means that HRV2 function is used, please add “–2048” to the
value of No.1988.
2) Please note that the position of optical connector on the 90Bx servo control card is a little
changed from that on 90Ax servo control card.
Concluded
