Additional Manual
3. Adapting software
The servo software 90Bx is basically upper compatible with the servo software 90Ax. And the
following functions are improved or added.
•
•
•
The function of low-frequency resonance elimination filter (disturbance elimination filter)
The function of high-frequency resonance elimination filter function (plural resonance
elimination filter)
The function to output the synchronous error on rigid tapping to the check board
The following error message may be displayed by a wrong combination with CNC software, servo
software, and servo control card.
[FS16i/18i/21i/160i/180i/210i/160is/180is/210is-MODEL A]
Series of CNC software for supporting the servo software 90Bx are displayed in (1)-1.
CNC software Servo card Servo soft Combination Alarm
Support 90Bx 90Ax card 90B0 × ALM403
Support 90Bx 90Bx card 90A0 × ALM403
Not support 90Bx 90Ax card 90B0 × ALM403
Not support 90Bx 90Bx card 90A0 × ALM920
Not support 90Bx 90Bx card 90B0 × ALM403
Support 90Bx 90Bx card 90B0
○
Support 90Bx 90Ax card 90A0
○
Not support 90Bx 90Ax card 90A0
○
[FS15i/150i-MODEL A]
Edition of CNC software for supporting 90Bx are F006 / F606 edition 03 or later.
CNC software Servo card Servo soft Combination Alarm
Support 90Bx 90Ax card 90B0 ×
SERVO ROM/MODULE
UNMATCH
Support 90Bx 90Bx card 90A0 ×
SERVO ROM/MODULE
UNMATCH
Not support 90Bx 90Ax card 90B0 ×
SERVO ROM/MODULE
UNMATCH
Not support 90Bx 90Bx card 90A0 ×
SERVO ROM/MODULE
UNMATCH
Not support 90Bx 90Bx card 90B0 × SERVO MODULE MISMATCH
Support 90Bx 90Bx card 90B0
○
Support 90Bx 90Ax card 90A0
○
Not support 90Bx 90Ax card 90A0
○
