Series 0i - Model A Connection manual (Hardware) Page 140

Connection manual (Hardware)
B–63503EN/02
9. CONNECTION TO FANUC I/O Link
128
Item Specification Note
General–purpose DI points 32 points 24VDC type input
General–purpose DO points 8 points 24VDC type output
Keyswitches of Machine operator’s panel 55 keys Matrix DI
LED Color : Green Attached to all keyswitches, Matrix DO
MPG interface Max. 3 units Only available for 0i.
Interface to CNC FANUC I/O Link connection Max. 16 modules or total points max.
1024/1024 will be available.
Sub panel specification
Item
A B
Note
Override rotary switch 2 2 5 bit Gray code output (with a parity bit)
Emergency stop switch 1 1 Number of Contact : 4 (Contact a 2,
Contact b 2) M3.5 Screw
Program protect key 1 1
ON/OFF switch ON/OFF –
Voltage Capacity Note
24VDC"10% (from Power connector
CA64, including momentary values)
0.4A Including all DI consumption
9.4.7.3
Main panel A/B
specification
9.4.7.4
Sub panel A, B1
specification
9.4.7.5
Power supply
specification
