Series 0i - Model A Connection manual (Hardware) Page 199

Connection manual (Hardware)
B–63503EN/02
A. EXTERNAL DIMENSIONS OF EACH UNIT
187
A
EXTERNAL DIMENSIONS OF EACH UNIT
Name Specification
Fig.,
No.
Basic unit (2–slot) A02B–0279–B502 Fig. U1
″
English display MDI
Symbol display MDI
A02B–0279–C041#TA
A02B–0279–C041#TAS
9
″
monochrome CRT/MDI unit (small size)
English display MDI
Symbol display MDI
A02B–0279–C041#MA
A02B–0279–C041#MAS
Fig. U2
″
English display MDI
Symbol display MDI
A02B–0279–C081#MA
A02B–0279–C081#MAS
8.4
″
TFT color LCD/MDI unit (small size, color)
English display MDI
Symbol display MDI
A02B–0279–C081#TA
A02B–0279–C081#TAS
Fig. U3
Interface board for high–speed serial bus (PC side/for ISA bus)
A20B–8001–0582
A20B–8001–0583
Fig. U4
Interface board for high–speed serial bus (PC side/for PCI bus)
A20B–8100–0960
A20B–8100–0961
Fig. U5
α position coder A860–0309–T302 Fig. U6
Manual pulse generator A860–0202–T001 Fig. U7
A860–0202–T004
A860–0202–T005
A860–0202–T007
Pendant type manual pulse generator
A860–0202–T010
Fig. U8
A860–0202–T012
A860–0202–T013
ABS battery case for separate type detector A06B–6050–K060 Fig. U9
Cable length : 1m A02B–0120–C181
Wide width type
Cable length : 2m A02B–0120–C182
Fig. U10
Cable length : 5m A02B–0120–C183
Punch panel
Cable length : 1m A02B–0120–C191
Narrow width type
Cable length : 2m A02B–0120–C192
Fig. U11
Cable length : 5m A02B–0120–C193
Main panel B A02B–0236–C231 Fig. U12
Machine operator’s panel
Sub panel B1 A02B–0236–C235 Fig. U13
″
English display MDI
Symbol display MDI
A02B–0279–C071#MA
A02B–0279–C071#MAS
7.2
″
monochrome LCD/MDI unit
English display MDI
Symbol display MDI
A02B–0279–C071#TA
A02B–0279–C071#TAS
Fig. U14
8.4″ TFT color LCD unit A02B–0279–C050 Fig. U15
10.4″ TFT color LCD unit A02B–0279–C060 Fig. U16
Stand–alone type MDI unit (small size)
English display MDI
Symbol display MDI
A02B–0279–C120#MA
A02B–0279–C120#MAS
Stand–alone type MDI unit (small size)
(for 9″ CRT and 8.4″ LCD, horizonatal type)
English display MDI
Symbol display MDI
A02B–0279–C120#TA
A02B–0279–C120#TAS
Fig. U17
Stand–alone type MDI unit (full–key)
English display MDI
Symbol display MDI
A02B–0279–C122#MA
A02B–0279–C122#MAS
Stand–alone type MDI unit (full–key)
(for 10.4″ LCD, vertical type)
English display MDI
Symbol display MDI
A02B–0279–C122#TA
A02B–0279–C122#TAS
Fig. U18
Machine operator’s panel Sub panel A A02B–0236–C232 Fig. U19
