1. Fanuc
  2. Series 16i/160i-LB

Series 16i/160i-LB Descriptions Page 15

Descriptions
B-63662EN/01 2.SPECIFICATIONS
- 9 -
Item Specifications
16i-LB 160i-LB
Remote diagnosis
Reading information for mounted printed
circuit board, CNC data such as
parameters, alarm status, etc.
**
Run time and parts number display
Actual cutting speed display
Floppy cassette directory display
Directory display and punch for a specified group
Graphic function
Dynamic graphic display
Servo adjustment screen
Servo waveform display Graphic display circuit is required * *
Hardware/software system configuration display
Periodic maintenance screen
Maintenance information screen
Software operator’s panel
General-purpose switch on software operator’s panel
Expansion of general–purpose switch on software
operator’s panel
Touch panel
External touch panel interface
English
Japanese (Chinese characters)
German/French
Italian
Spanish
Display language
Korean
Data protection key Four types
Screen clear
Data input/output
Item Specifications
16i-LB 160i-LB
Reader/puncher (channel 1) interface
Reader/puncher interface
Reader/puncher (channel 2) interface
Input/output simultaneous operation
Remote buffer
High-speed remote buffer A
Data server
External I/O device control
DNC1 control
DCN2 control
Modem card control
External tool offset
External message
External machine zero point shift
External data input Including above three items
External key input
External programming
External workpiece number search 9999
External program number search 1 to 9999 * *
Memory card input/output
Screen hard copy
Previous page
Next page
