Handy Machine Operator Supplement to Manual Page 77

Supplement to Manual
B-63753EN/01 PMC PROGRAMMING4.OUTLINE OF HANDY MACHINE OPERATOR'S PANEL FUNCTIONS
- 69 -
4.2.3 Input Keys
By using these input signals, state of 20 input keys can be read. When
the HMOP is disconnected or the power is off or communication
alarm is occurred, the signals will be all “0”.
Address Bit7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X+7
(Reserved) (Reserved) (Reserved) KEY15 KEY14 KEY13 KEY12 KEY11
X+8
(Reserved) (Reserved) (Reserved) KEY25 KEY24 KEY23 KEY22 KEY21
X+9
(Reserved) (Reserved) (Reserved) KEY35 KEY34 KEY33 KEY32 KEY31
X+10
(Reserved) (Reserved) (Reserved) KEY45 KEY44 KEY43 KEY42 KEY41
KEY11 to KEY45: Input keys
KEY11 to KEY45 Description
0 Input key is not pressed.
1 Input key is pressed.
When HMOP is viewed from the front, key array is as follows.
KEY11 KEY 12 KEY 13 KEY 14 KEY 15
KEY 21 KEY 22 KEY 23 KEY 24 KEY 25
KEY 31 KEY 32 KEY 33 KEY 34 KEY 35
KEY 41 KEY 42 KEY 43 KEY 44 KEY 45
4.2.4 Manual Pulse Generator (MPG)
By using these input signals, pulses from MPG can be read.
PMC need not handle these signals because CNC handles these
directly.
Address Bit7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X+12 MPG7 MPG6 MPG5 MPG4 MPG3 MPG2 MPG1 MPG0
Bits 0 to 7 : Pulses from MPG
Bits 0 to 7 Description
MPG0 to MPG7 Count of pulses from MPG
This value changes only when OPSW(Operation on/off switch) is
1(enable).
