Handy Machine Operator Supplement to Manual Page 91

Supplement to Manual
B-63753EN/01 PMC PROGRAMMING 5.DI/DO INFORMATION TABLE
- 83 -
5.1 INPUT SIGNALS
address Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X+0
PWR08 PWR07 PWR06 PWR05 PWR04 PWR03 PWR02 PWR01
X+1
PWR16 PWR15 PWR14 PWR13 PWR12 PWR11 PWR10 PWR09
X+2
- - PWR22 PWR21 PWR20 PWR19 PWR18 PWR17
X+3
ERINF-------
X+4
- - - OVREN OVR3 OVR2 OVR1 OVR0
X+5
- - - OPSW EQDSW DSW2 DSW1 ESP
X+6
- - - - LCDER2 LCDER1 LCDER0 ACKLCD
X+7
- - - KEY15 KEY14 KEY13 KEY12 KEY11
X+8
- - - KEY25 KEY24 KEY23 KEY22 KEY21
X+9
- - - KEY35 KEY34 KEY33 KEY32 KEY31
X+10
- - - KEY45 KEY44 KEY43 KEY42 KEY41
X+11
--------
X+12
MPG7 MPG6 MPG5 MPG4 MPG3 MPG2 MPG1 MPG0
X+13
--------
X+14
--------
X+15
--------
