4.OUTLINE OF HANDY MACHINE OPERATOR'S PANEL FUNCTIONS PMC PROGRAMMING B-63753EN/01
- 78 -
• Rounding are done according to this setting when effective
number of digits below the decimal point of numeric variable is
larger than the number of digits specified with DSPDE0-2
(Number of display columns below decimal point).
(Example) “Value of numeric variable=13.45,
Number of display columns below decimal point=1,
Number of display columns = 4 “ Situation.
DSPPRC Display of four digits
0: Round-down 1 3 . 4
1: Half-adjust 1 3 . 5
Bit 4: Display location
Bit 4
DSPPOS
Description
0 Numeric variable is displayed in right justify in the display
column number specified with DSPCL 0-4.
1 Numeric variable is displayed in left justify in the display
column number specified with DSPCL 0-4
• When “Right justify” is specified, the character specified with
LZERO is displayed on vacant of the left side.
• When “Left justify” is specified, vacant of the right side
becomes blank.
Bit 5: Character stuffed at the left of displayed numerical value
Bit 5
LZERO
Description
0 The space character is stuffed with.
1
The ‘0’ character is stuffed with. When numeric variable is a
negative number, this item cannot be specified.
• When the digits of data is less than the number of display
columns which specifies with DSPCL0-4, and specifies “Right
justify” with DSPPOS, this setting is effective.
(Example) “Value of numeric variable=1234, Number of
display columns = 4 “ Situation
DSPPOS LZERO
Display of six digit
0: right justify 0: Space 1 2 3 4
0: right justify 1: ‘0’. 001234
1: left justify 0: Space 1234
1: left justify 1: ‘0’ 1234
