(5) 84 command (Circular move)
This command informs the end position of Circular move(end position of circular
move block of NC program).
84
1
@1
5 4 2 3
@2
9 8 6 7
@3
13 12 10 11
@4
17 16 14 15
@5
21 20 18 19
@6
25 24 22 23
@7
bit0
bit7
@1
Arc 1 axis
Arc 2 axis
00：actual first axis
01：actual second axis
02：actual third axis
Rotate direction
0：CW
1：CCW
@2 End point of circular move (first axis)
@3 End point of circular move (second axis)
@4 End point of circular move (third axis)
@5 Center point of circular move (first axis)
@6 Center point of circular move (second axis)
@7 Center point of circular move (third axis)
EDIT DATE DSGN DESCRIPTION
RELEASE
DSGN RECOG
TITLE
DRAWING No.
Sheet
10/14
Specifications of
CNC-PC Graphic Interface
A-61184E
970702
Murata
02
03
04
971117
971216
980116
Murata
Murata
Samukawa
Samukawa
Samukawa
The parts of ② are added.
FC command is added. ③
Spec. of FC command is changed. ④
