Specifications of CNC-PC Graphic Interface Additional Manual Page 14

Additional Manual
@1 number of sending M code (1/2/3)
@2 1st
@3 2nd
M code
M code
M code
@4 3rd
@3 and @4 are not sent when @1 is 1, and also @4 is not sent when @1 is 2. In
other words, the length of data is changed according to the number of sending M code.
Example of graphic commands order for punch animation
7F Set coordinate
81 Set draw start position
BD Select tool
85 Set rapid speed ratio
86 Rapid move
83 Linear move
ED Punch action(draw tool figure on PC monitor)
84 Circular move
ED Punch action(draw tool figure on PC monitor)
EC Tool rotation
83 Linear move
ED Punch action(draw tool figure on PC monitor)
86 Rapid move
FC M code output
BF Draw(animation) end
EDIT DATE DSGN DESCRIPTION
RELEASE
DSGN RECOG
TITLE
DRAWING No.
Sheet
14/14
Specifications of
CNC-PC Graphic Interface
A-61184E
970702
Murata
02
03
04
971117
971216
980116
Murata
Murata
Samukawa
Samukawa
Samukawa
The parts of ② are added.
FC command is added. ③
Spec. of FC command is changed. ④
