  2. Specifications of CNC-PC Graphic Interface

Specifications of CNC-PC Graphic Interface Additional Manual Page 13

Additional Manual
(9) BF command (animation end)
This command informs the end of NC program.
BF
(10) EC command (tool rotation)
This command informs the rotation angle of tool.
EC
4 3 1 2
@1
@1 C-axis rotation angle of tool
(11) ED command (punch action)
This command informs the punch action.
ED
(12) FC command (M code output) ③ ④
This command informs the kind of M code.
FC
1
@1
5
4 2 3
@2
9
8
6 7
@3
13
12
10 11
@4
EDIT DATE DSGN DESCRIPTION
RELEASE
DSGN RECOG
TITLE
DRAWING No.
Sheet
13/14
Specifications of
CNC-PC Graphic Interface
A-61184E
970702
Murata
02
03
04
971117
971216
980116
Murata
Murata
Samukawa
Samukawa
Samukawa
The parts of ② are added.
FC command is added. ③
Spec. of FC command is changed. ④
