  2. Specifications of CNC-PC Graphic Interface

Specifications of CNC-PC Graphic Interface Additional Manual Page 3

Additional Manual
CNC sets the cancel flag if it requests PC to stop reading the graphic commands.
Check animation stop
“cnc_stopdyngrph”
Cancel flag read
“cnc_rdgrphcanflg”
Instruction receive status
Execute end process
Cancel flag set
Data Window I/F
Data Window I/F
Data Window I/F
・Stop reading graphic commands.
・Delete all graphic commands
in graphic command I/F
“cnc_clrgrphcmd”
Stop Graphic commands output
Generate Graphic commands
～ ～
Data Window I/F
Data window I/F is an interface between CNC and PC for library functions. The library
functions are delivered from FANUC as library for Microsoft Windows
®
95.
Graphic Command I/F
Graphic Command I/F is an interface between CNC and PC for transferring graphic
commands for animation. It is the ring buffer and arranged with 1word unit. CNC writes
data to this area,and PC(application) reads data from this area.
EDIT DATE DSGN DESCRIPTION
RELEASE
DSGN RECOG
TITLE
DRAWING No.
Sheet
3/14
Specifications of
CNC-PC Graphic Interface
A-61184E
970702
Murata
02
03
04
971117
971216
980116
Murata
Murata
Samukawa
Samukawa
Samukawa
The parts of ② are added.
FC command is added. ③
Spec. of FC command is changed. ④
