Example

Assume the following conditions:

• Specified workpiece coordinate system: G56

• G56 workpiece origin offset (X-axis): 50.000

• G56 workpiece origin offset (Z-axis): 5.000

• G56 workpiece origin offset (C-axis): 180.000

• G56 workpiece origin offset (Y-axis): -60.000

• Amount of manual feed-based movement along the X-axis: -10.000 mm

• Amount of manual feed-based movement along the Z-axis: 10.000 mm

• Amount of manual feed-based movement along the C-axis: 90.000 degrees

• Amount of manual feed-based movement along the Y-axis: -5.000 mm

Under the above conditions, the workpiece origin offset for G56 is changed

as follows:

• X-axis: 50.000 + (-10.000) = 40.000

• Z-axis: 5.000 + 10.000 = 15.000

• C-axis: 180.000 + 90.000 = 270.000

• Y-axis: -60.000 + (-5.000) = -65.000

2.5 Presetting the relative position indicator

Setting parameter APL (No. 3115#5) to 1 can preset the relative position

indicator (counter) to 0 automatically when active offset change mode is selected.

In this case, performing manual feed until the relative position indicator

(counter) becomes 0 can restore the changed offset value to the previous one.

2.6 Tool life management

If a tool management option is available, compensation is carried out by the T

code (Txx99). In this case, a change is made to the compensation corresponding

to the compensation number made valid by this command.

2.7 Emergency stop and SV alarm

If the servo power is switched off (for example, when the machine is brought to an

emergency stop or an SV alarm occurs), axis movement caused by follow-up is

reflected to the offset during active offset change mode.

NOTE

If the tool compensation has been selected as an offset to be changed, follow-up-caused

axis movement around a rotation axis is not reflected to the offset

Edit

Apprv.

Desig.

Sheet

Title

Draw

No.

Date

Design

Descri

tion

Date

FANUC Series16i/18i/21i–TA/TB

Changing Active Offset Value

with Manual Move.

-78376

03 Jan.21.’02 Addition and modification of (3)

02 Feb.08.’01 T.Endo Overall revisio H.Kochiya

Jan.16.’01 T.Endo H.Kochiya

4/10
