B–63832EN/01

2. LIST OF SPECIFICATIONS GENERAL

LIST OF SPECIFICATIONS

f : Standard fA : Standard of Package A fB : Standard of Package B F : Standard option

l : Option lA : Option of Package A : : Function included in another option — : Not available

Note) Some combinations of these options are restricted.

In case of CNC Display with Personal Computer function,

using CNC Screen Display Function is a premise.

Item

Specifications

Series 0i

Mate

Item

Specifications

MB TB MB TB

Controlled axis

Controlled path 1 path f f f f

xes

4 axes f l — —

d a

Controlled axis (Including

3 axes — — f —

olle

Cs axes)

2 axes — f — f

ntro

Max. 4 axes f f — —

Simultaneously controlled

Max. 3 axes — — f —

ine

axes

Max. 2 axes — — — f

ach

Axis control by PMC Max. simultaneous 4 axes (Not available on Cs axes) f f — —

Cs contouring control 1 axis f f — —

Basic three axes are X, Y and Z, additional axes are op-

tional from U, V, W, A, B and C.

f — f —

Axis name

In case of G code system A, basic 2 axes are X and Z,

additional axes are optional from Y, A, B and C.

— f — f

In case of G code system B/C, basic 2 axes are X and Z,

additional axes are optional from Y, U, V, W, A, B and C.

— f — f

2 units f f — —

Spindle

1 unit — — f f

Simple synchronous control f f — —

Angular axis control l l — —

Least input increment 0.001mm, 0.001deg, 0.0001inch f f f f

Increment system 1/10 0.0001mm, 0.0001deg, 0.00001inch f f — —

Flexible feed gear Optional DMR f f f f

Fine Acc & Dec control f f f f

HRV1 fB fB f f

Servo HRV control

HRV3 fA fA — —

Inch/metric conversion f f f f

Interlock

All axes/each axis/each direction/block start/cutting block

start

f f f f

Machine lock All axes/each axis f f f f

Emergency stop f f f f

Overtravel f f f f

Stored stroke check 1 f f f f

Stroke limit external setting f — f —

Stored stroke check 2 f — f —

Stored stroke check 2, 3 — f — f

Chuck and tail stock barrier — f — f

Mirror image Each axis f f f f
