Series 0i/0i Mate - Model B Descriptions Page 33

Descriptions
B–63832EN/01
2. LIST OF SPECIFICATIONSGENERAL
9
Item
Series 0i
Mate
Series 0i
SpecificationsItem
TBMBTBMB
Specifications
Feed function
AI contour control lA — — —
Program input
Tape code EIA RS244/ISO840 f f f f
Label skip f f f f
Parity check Horizontal and vertical parity f f f f
Control in/out f f f f
Optional block skip 9 f f f f
Max. programmable dimension 8–digit f f f f
Program number O4–digit f f f f
External memory and sub program
calling function
f f f f
Sequence number N5–digit f f f f
Absolute/incremental programming Combined use in the same block f f f f
Decimal point programming/ pocket
calculator type decimal point pro-
gramming
f f f f
Input unit 10 time multiply f f f f
Diameter/radius programming (X
axis)
— f — f
Plane selection G17, G18, G19 f f f f
Rotary axis designation f f — —
Rotary axis roll–over f f — —
Polar coordinate command f — f —
Coordinate system setting f f f f
Automatic coordinate system set-
ting
f f f f
Coordinate system shift — f — f
Direct input of coordinate system
shift
— f — f
Workpiece coordinate system G52 to G59 f f f f
Workpiece coordinate system pre-
set
f f f f
Addition of workpiece coordinate
system pair
48 pairs f — f —
Direct input of workpiece origin off-
set value measured
f f f f
Manual absolute on and off f f f f
Direct drawing dimension program-
ming
— f — f
G code system A/B/C — f — f
Optional chamfering/corner R f — f —
Programmable data input G10 f f f f
Sub program call 4 folds nested f f f f
Custom macro B f f f f
Addition of custom macro common
variables
#100 to #199, #500 to #999 f f f f
Pattern data input f f f f
Interruption type custom macro f f f f
Canned cycles — f — f
