Series 0i/0i Mate - Model B Descriptions Page 335

Descriptions

Page of 412

/ 412

B–63832EN/01

1. GENERAL

AUTOMATIC PROGRAMMING

FUNCTION

311

GENERAL

Manual Guide 0i was developed to aid in generating a machining program

for the Series 0i–B. Manual Guide 0i is provided for lathes and machining

centers (or milling machines).

A machining program, in which alphabetical addresses and numerical

values are paired, includes a series of machining commands specified by

the operator. This enables a CNC program to be created as a series of

commands that perform machining operations. Multiple machining

commands can be combined to perform complicated machine work.

Manual Guide 0i can also edit an exiting machining program. Online help

that comes with the product can be used during development of a program

or used as a reference for programming.

Manual Guide 0i has the following functions.

1) Process data input

Helps the operator to input process data such as the cutting speed or

spindle rotation commands.

2) G–code assistance

Uses text or a figure to describe G–codes that can be normally used by

the CNC and assist in inputting the codes.

3) M–code assistance

Describes M–codes that can be used by the machine and assists in

inputting the codes. Machine tool builders can change an indicated M

code by using the macro executor.

4) Cycle machining

Manual Guide 0i for machining centers (or milling machines) allows

drilling, facing of standard figures, pocketing, and grooving to be

input and executed as cycle machining.

Manual Guide 0i for lathes allows turning drilling, turning

rough/finish machining of an arbitrary figure, turning grooving, and

turning threading to be input and executed as cycle machining.

5) Contour programming

Allows input of an arbitrary figure consisting of lines and circles. This

contour programming function includes advanced figure calculations

such as 10–block pending calculation or 11–pattern auxiliary

calculation.
