B–62075E/04

3. INPUT AND OUTPUT OF DATA

214

1 Set the emergency stop state.

2 Display the parameter screen.

1) Press the

SERVICE

key.

2) Press the

function menu key.

3) Press the [CHAPTER] soft key.

4) Press the [PARAM] soft key.

The parameter screen can also be displayed by pressing the

SERVICE

key

several times.

3 Check that bit 0 of setting data No. 8000 is set to 1. If the bit is set to

0, set the bit to 1 according to the parameter setting procedure

described in Section 3.1.

4 Press the

operation menu key to display [READ] in the soft key

menu.

5 Press the [READ] soft key. Then, the soft key menu changes again to

display the [PARAM] soft key.

6 Press the [PARAM] soft key to start parameter input.

7 Upon the completion of parameter input, turn the power off, then back

on again.

(1)Setting the input/output channel

When inputting and outputting data, the input/output channel must be

correctly set. Once the input/output channel has been set, the setting

is maintained even after the CNC is turned off. Therefore, further

channel setting is normally not required. If the input/output channel

must be again set for some reason, follow the steps below.

1. Press the

PMC

CNC

key to display the PMC screen. When the lower soft

key list as shown in the figure below is displayed on the PMC

screen, steps 2. to 8. are not needed.

PCMDI

RUN/STOP

PCLAD

EDIT

PDDGN

I/O

PCPRM

SYSPRM

For the 9″ CRT

– ETC –

2. Press the

PMC

CNC

key to display the NC screen. Then put the CNC

in the MDI mode or emergency stop mode.

3.2.3

Data Input

3.2.3.1

CNC parameter input

3.2.3.2

Inputting CNC parameter

D PMC–NA
