B–62075E/04

5. TROUBLESHOOTING

277

Operation mode status is displayed on the lower part of CRT as

follows :

If nothing is displayed, mode select signal is not input. Check mode

select signal using PMC’s diagnostic function (PMCDGN).

For details, refer to section 1.6 NC STATUS DISPLAY.

(Example of display)

JOG : Manual operation (JOG) mode

HND : Manual handle (MPG) mode

MDI : Manual data input (MDI) mode

MEM : Automatic operation (Memory) mode

EDIT: EDIT (Memory edit) mode

G003

EDT

MEM

(M/T series)

G097

EDT

MEM

#4 #3

(TT series)

↓↓↓↓↓↓↓↓

0Incremental (INC) feed 0 0 0 0 0 0 1

0Manual handle (HND) feed 0 0 0 0 0 1 0

0Jog (JOG) feed 0 0 0 0 1 0 0

0Manual data input (MDI) 0 0 0 1 0 0 0

0Tape command (TAPE) 0 0 1 0 0 0 0

0Memory command (MEM) 0 1 0 0 0 0 0

0Tape storage and editing (EDT) 1 0 0 0 0 0 0

(2)Check the status according to CNC diagnostic function Nos. 1000 and

1001. Investigate any items for which 1 is displayed on the right.

No. 1000

a. INPOSITION CHECK

FEEDRATE OVERRIDE 0

b. JOG FEED OVERRIDE 0

c. INT./START LOCK ON

SPEED ARRIVAL ON

WAIT REVOLUTION

STOP POSITION CODER

FOREGROUND READING

No. 1001

BACKGROUND READING

a. In–position check (positioning check) is being performed.

The system indicates that axis movement has not been completed.

Check the state of the following diagnostic number. (This item will

be 1 under the following condition.)

Diagnostic No. 3000 (position deviation) > Parameter No. 1827

(in–position width)
