(1) If 0 ≤ θ ≤ ∆θ, θ is regarded as 0deg.
θ
∆θ
V
Tn
V
Mn+1
Fig.1.2 (i) Determination of θ
θθ
θ=0deg.
(2) If (180-∆θ) ≤ θ ≤ 180, θ is regarded as 180deg.
θ
∆θ
V
Tn
V
Mn+1
Fig.1.2 (j) Determination of θ
θθ
θ=180deg.
(3) If (90-∆θ) ≤ θ ≤ (90+∆θ), θ is regarded as 90deg.
θ
∆θ
V
Tn
V
Mn+1
θ
∆θ
V
Tn
V
Mn+1
Fig.1.2 (k) Determination of θ
θθ
θ=90deg.
(2) Compensation vector whenθ is regarded as 0deg.or 180deg.
If θ is regarded as 0deg.or 180deg.when G41.3 is specified to start
leading edge compensation, alarm PS998 is issued. This means that
the tool vector of the current block and the movement vector of the
next block must not point in the same direction or in opposite
directions at start-up.
The previously created compensation vector is maintained other
than at start-up at all times.
If the included angles between V
T2
and V
M3
, V
T3
andV
M4
, and V
T4
and V
M4
, and V
T4
and V
M5
are regarded as 05, the compensation
vector V
C1
of block 1 is maintained as the compensation vectors
V
C2
, V
C3
, and V
C4
, of blocks 2, 3, and 4, respectively.
Previous page
Next page

Contents Summary of 3-dimensional cutter compensation Additional Manual
