Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual Page 12

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
F
A
NUC Series 30i-MODEL A
Memory Card Program
Operation/Editing
A
-79368E
Sep.11.’03
10/12
page
Title
Draw
No.
Descri
p
tion
・Main program selection
Pressing the [MAIN PROGRAM] soft key selects, as a main program, the program currently
selected with the cursor.
・Display switching
Pressing the [DETAIL] soft key switches folder/file display to detail display. Pressing the
[OUTLINE] soft key switches the screen display to outline display.
Limitation
When a program storage memory card is selected, the following operations cannot be
performed:
- Program/folder creation
- Program/folder deletion
- Program attribute/folder attribute modification
- Program number (name)/folder name modification
- Program arrangement
- Program input/output
- Program copy/move
When an external device subprogram is called (M198) from a memory card (by setting bit 7
(MNC) of parameter No. 0138 to 1), the contents of the program storage file cannot be
displayed during automatic operation.
