Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual Page 7

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
F
A
NUC Series 30i-MODEL A
Memory Card Program
Operation/Editing
A
-79368E
Sep.11.’03
5/12
page
Title
Draw
No.
Descri
p
tion
1.1.3 Limitations and Cautions on Memory Card Programs
Limitation
When a program storage memory card is selected, the memory card cannot be used for the
ordinary purposes listed below. To use a memory card in such a case, perform a "removal"
operation to cancel the recognition of the program storage memory card. For details of the
operation, see Subsection 1.2.1, "Program Directory Screen".
・ ALL I/O screen
Display of the contents of a memory card, and reading/punching data to and from a
memory card
・ PMC data I/O screen
Display of the contents of a memory card, and reading/punching to and from a memory
card
・ Program directory screen
Reading/punching program data to and from a memory card
・ External device subprogram call (M198) operation
Subprogram call (M198) with a memory card set as an external device
Caution
CAUTION
1 Do not remove the memory card when a program that specifies a write
to the memory card is being edited. The data can be destructed.
2 If an editing operation is completed, the results of editing are preserved
even when the power to the CNC is turned off.
3 When removing the memory card, be sure to perform a "removal"
operation. If the memory card is removed without performing a
"removal" operation and an attempt is made to access the memory
card, the SR1964 alarm or IO1030 alarm is issued.
If the card is removed inadvertently, insert the card again and perform
a "removal" operation.
When an alarm is issued, perform the following operation:
・When the SR1964 alarm is issued
Reset the alarm after performing a "removal" operation.
・When the IO1030 alarm is issued
The alarm can be reset only by turning off the power to the CNC.
4 Do not attempt to replace the memory card without performing a
"removal" operation. Such an attempt is very dangerous.
