Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual Page 5

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
F
A
NUC Series 30i-MODEL A
Memory Card Program
Operation/Editing
A
-79368E
Sep.11.’03
3/12
page
Title
Draw
No.
Descri
p
tion
NOTE
To use the functions for calling macros, using custom macros, and
using a multiple repetitive canned cycle for turning, the options
corresponding to the respective functions are required.
・Selection as a main program
As a main program to be automatically executed in the memory mode, a memory card
program can be selected.
・Sub program (call using M98/G72.1/G72.2)
・Macro program (call using G65/G66/G66.1/M96)
The following subprogram/macro program held in the same folder as containing the main
program is called:
- Sub program call (M98)
- Macro call (Simple macro call G65 / Modal call G66,G66.1)
- Macro interrupt (M96)
- Figure copying (G72.1, G72.2)
If the program cannot be found in the same folder as the main program, the following folder
is searched:
- Common program folder on the CNC_MEM device (CNC program storage memory)
NOTE
To use the functions for macro call, macro interrupt, and figure
copying, the options corresponding to the respective functions are
required.
・Sub program (call using M code/S code/T code/particular address/the second auxiliary function)
・Macro program (call using G code/M code)
The following subprogram/macro program calls a program from the CNC_MEM device
(CNC program storage memory):
- Subprogram call using M code/S code/T code/particular addresses/the second auxiliary
function
- Macro call using G code/M code
The folders set as search targets are searched in the following order, and the first found
program is called:
1 Common program folder among the initial folders
2 MTB-dedicated folder 2 among the initial folders
3 MTB-dedicated folder 1 among the initial folders
