Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual Page 2
Additional Manual
FANUC Series30i –A newly additional functions
Drawing number Functions
1 A-79227E
External Data Input
2 A-79226E One Touch Macro call
3 A-79196E
Temporary absolute coordinate setting
4 A-79354E
System alarm
5 A-79349E Touch Panel Control
6 A-79253E
Distance coded linear scale interface
7 A-79364E
Linear scale with distance-coded reference marks (serial)
8 A-79343E Input of tool offset Value Measured
9 A-79344E Input of tool offset Value Measured B
10 A-79345E Tool Management Extension Function
11 A-79346E Tool Management Function Oversize tools Support
12 A-79342E
External touch panel interface
13 A-79348E Tool center point control for 5-axis machining
14 A-79381E Tool axis direction tool length compensation
15 A-79355E
Index Table Indexing Function
16 A-79356E
Rotary axis control function
17 A-79357E
Extended External Machine Zero Point Shift function
18 A-79340E
Diameter and Radius setting switching function
19 A-79341E
Active offset value change function based on manual feed
20 A-79358E
Single Direction Positioning function
21 A-79366E
Background Editing
22 A-79368E
Memory Card Program Operation/Editing
23 A-75359E
Rotary table dynamic fixture offset
24 A-79351E
Three-Dimensional Error Compensation
25 A-79260E
Power Mate CNC Manager
26 A-79350E
Real-time Custom Macro
27 A-79360E
Improvement of stored stroke limit 1
28 A-79361E
Start lock, Interlock signal for each axis and direction
29 A-79367E
Rapid traverse override 0.1%
30 A-79363E
In-position check and servo error excess check in Torque limit
31 A-79414E
Small-Hole Peck Drilling Cycle
32 A-79352E
I/O Link β Manual handle interface
(Peripheral equipment control interface)
Contents Summary of Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual
- Page 1TECHNICAL REPORT NO. TMN 04/020E Date :Mar .30, 2004 General Manager of Software Laboratory FANUC Series 30i-A Newly additional functions 1. Communicate this report to: Your information only GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON Machine tool builder Sales agency End user 2. Summary for Sale
- Page 2FANUC Series30i –A newly additional functions Drawing number Functions 1 A-79227E External Data Input 2 A-79226E One Touch Macro call 3 A-79196E Temporary absolute coordinate setting 4 A-79354E System alarm 5 A-79349E Touch Panel Control 6 A-79253E Distance coded linear scale interface 7 A-79364E Li
- Page 3FANUC Series 30i-MODEL A Memory Card Program Operation/Editing Specifications FANUC Series 30i-MODEL A Title Memory Card Program Operation/Editing Draw A-79368E No. Edit Date Design Description page 1/12 Date Sep.11.’03 Desig. Apprv.
- Page 41.1 MEMORY CARD PROGRAM OPERATION/EDITING Overview A program held in a program storage file (named "FANUCPRG.BIN") on the memory card can be selected as a main program to perform memory operation. Moreover, the contents of a program storage file can be referenced using the program directory screen,
- Page 5NOTE To use the functions for calling macros, using custom macros, and using a multiple repetitive canned cycle for turning, the options corresponding to the respective functions are required. ・Selection as a main program As a main program to be automatically executed in the memory mode, a memory ca
- Page 64 System folder among the initial folders Search target folders are set in parameter No. 3457. NOTE For a memory card program, subprogram call using M code/S code/T code/particular addresses/the second auxiliary function or macro call using G code/M code can be specified. However, a program on the C
- Page 71.1.3 Limitations and Cautions on Memory Card Programs Limitation When a program storage memory card is selected, the memory card cannot be used for the ordinary purposes listed below. To use a memory card in such a case, perform a "removal" operation to cancel the recognition of the program storage
- Page 81.1.4 Creating a Memory Card Program Create a program storage file ("FANUCPRG.BIN") on a commercially available personal computer by using a memory card program creation tool. The number of program storage file entries (total number of program files and folders) can be selected from the following: ・
- Page 9Example ・Contents of the program storage file ("FANUCPRG.BIN") Folder Program file not handled as program number Program file handled as program number Limitation ・The folder attribute/program file attribute cannot be set. FANUC Series 30i-MODEL A Title Memory Card Program Operation/Editing Draw A-7
- Page 101.2 OPERATION SCREENS Overview The contents of a program storage file on the memory card can be displayed on the program directory screen. For information about a program storage file, see Subsection 1.1.4, "Creating a Memory Card Program". 1.2.1 Program Directory Screen When a program storage memor
- Page 11Operation When displaying the contents of a program storage file or selecting a main program, select a program storage memory card by device change operation. ・Device change operation Insert a program storage memory card into the card slot then press the [DEVICE CHANGE] soft key. Next, select the pr
- Page 12・Main program selection Pressing the [MAIN PROGRAM] soft key selects, as a main program, the program currently selected with the cursor. ・Display switching Pressing the [DETAIL] soft key switches folder/file display to detail display. Pressing the [OUTLINE] soft key switches the screen display to ou
- Page 131.2.2 Program Editing Screen When a memory card program is selected as a main program, the following editing operations can be performed: - Insertion - Deletion - Replacement - Search Limitation When a program storage memory card is selected, the following operation cannot be performed: - Punching/r
- Page 141.3 PARAMETER #7 #6 #5 #4 #3 #2 #1 #0 0138 MNC [Input type] Parameter input [Data type] Bit axis #7 MNC The external device subprogram call (M198) from a memory card is 0: Disabled 1: Enabled #7 #6 #5 #4 #3 #2 #1 #0 3457 SYS MC1 MC2 LIB [Input type] Parameter input [Data type] Bit axis #0 LIB The co
