4 System folder among the initial folders
Search target folders are set in parameter No. 3457.
NOTE
For a memory card program, subprogram call using M code/S code/T
code/particular addresses/the second auxiliary function or macro call
using G code/M code can be specified. However, a program on the
CNC_MEM device (CNC program storage memory) is called.
Limitation
- For a memory card program, M198 cannot be specified. Moreover, no memory card
program can be called from a program on the CNC_MEM device (CNC program storage
memory) by specifying M198.
1.1.2 Memory Card Program Editing
A memory card program can be edited.
The following editing operations can be performed:
- Insertion
- Deletion
- Replacement
- Search
Other available functions
The following functions can be used with a memory card program:
- External program number search
- External workpiece number search
Limitation
The following operations cannot be performed on programs (memory card programs) and
folders in a program storage file:
- Program/folder creation
- Program/folder deletion
- Program attribute/folder attribute modification
- Program number (name)/folder name modification
- Program arrangement
- Program input/output
The following function cannot be used with a memory card program:
- Key and program encryption
