FS 16i/18i/21i-MA/MB, FS 18i-MB5 Additional Manual Page 10

Additional Manual
1.3. In the case of a rotary axis A type
In the case of a rotary axis A type, when machine position passes 0 degree or the
shift value per one rotation (360 degree or the parameter No.1260), the data for the
reference position (the parameter No.1860, 1861) is renewed so that following up at
power up is within one rotation. But as for the rotary axis A type using a scale without
rotary data, the data for the reference position (No.1860, 1861) need not be renewed
because scale data without rotary data is always read at turning on.
#7 #6 #5 #4 #3 #2 #1 #0
1815 NRTx
[Data type] Bit axis
NRTx Specifies to renew the reference position (No.1860, 1861) when machine
position passes 0 degree or the shift value per one rotation (360 degree or No.1260)
0: to renew
1: not to renew
NOTE
・ It is necessary to turn the CNC off after setting this parameter.
・ This parameter is available for only the rotary axis A type.
・ This parameter must be set for the rotary axis A type using a scale
without rotary data.
In case that this parameter is not set to the rotary axis A type using a
scale without rotary data, the following phenomena may be generated.
- It may take long time to establish the machine coordinate at CNC
power on.
- The correct machine coordinate may not be established at CNC
power on after many rotations in the same direction.
・ Perform reference position establishment again when this parameter
was changed.
#3
#3
For No.1815#6(NRT) all FS16i /18i /20i/21i software is allowed.
Edit
Apprv Desig.
9/12
Date
Design
Description
Data
FANUC Series 16i /18i /21i –MA/MB, 18i -MB5
Setting of parameters for rotary scale without
rotar
y data
A-78823E
03 Dec.02.2003 Out of #3 is added.
02 Feb.25.2003
M.tanaka
Out of #2 is altered / added.
Feb.20.2003
Sheet
Title
Draw
No.
