【Reference counter capacity】
No.1821
Set amount of feed back pulsees (detection unit) per a table rotation.
NOTE) Set amount of (pulses per a table rotation / 8) as reference counter capacity
in the case of No.2275#0=0. But in this case eight grids are made every a
table rotation.
(Example of parameters setting)
【System construction】
Heidenhain rotary encorder RCN223
The least input increment is 1/10,000 degree
In the case that moving distance is 180 degree every a motor rotation
(deceleration ratio is 1/2)
Deceleration ratio between a table and a separate encorder = 1/1
【Setting parameters】
・Set No.1815#1=1 so that separate detector is available.
・Set No.2275#0=1、No.2275#1=1、No.2394=8 so that RCN223 is used.
・Parameters for flexible feed gear are calculated.
flexible feed gear (N/M) = (360 degree / 0.0001 degree) / 8,000,000 =9 / 20
So, No.2084=9, No.2085=20
・Amount of positional paluses is calculated.
amount of positional paluses = 100,000 * (1 / 2) = 50,000
Because this value exceeds input range (0~32767), following is considered
50,000 = 12,500 * 4 --> A = 12,500 , B=4
A is set for “amount of positional paluse” and B is set for “positional pulse
conversion coefficient”
No.2024＝12,500 , No.2185=4
・Reference counter capacity is calculated.
reference counter capacity = 360 degree / 0.0001 degree = 3,600,000
