An uncontinuous point of scale data
Before using this function it is necessary to know the position of the uncontinuous
point in following process.
1. Perform a reference position return with No.1817#3=0.
2. Record machine coordinate value after moving to one side of movable range.
3. Turn the CNC off and on.
4. In the case that machine coordinate value misses by 360 degree, it is
necessary to know the uncontinuous position because it exists within movable
range. Go to the process 7.
In the case that machine coordinate value does not miss and CNC starts
normally, record machine coordinate value after moving to the other side of
movable range.
5. Turn the CNC off and on.
6. In the case that machine coordinate value misses by 360 degree, it is
necessary to know the uncontinuous position because it exists within movable
range. Go to the process 7.
In the case that machine coordinate value does not miss and CNC starts
normally, it is unnecessary to use this function because there is not an
uncontinuous point within movable range. It is possible to use with
No.1817#3=0.
7. Record machine coordinate value after moving by an constant interval (10
degree, for example) from present position for a inside of movable range.
#2
8. Turn the CNC off and on.
9. Repeat process 7, 8. The CNC starts on wrong position until exceeding an
uncontinuous point. After exceeding an uncontinuous point, the CNC starts on
correct position.
#2
By the above process it is possible to know the approximate position of the
uncontinuous point.
In the case of the figure (page 4) :
1. A reference position return finishing.
2. Moving to machine coordinate value -45.000.
3. Turnning the CNC off and on.
4. Moving to machine coordinate value 45.000 (the other side) because machine
coordinate value at power on (-45.000) is correct.
5. Turnning the CNC off and on.
6. Starting on -315.000 with machine coordinate missing by 360 degree.
7. Shifting by 10 degree and moving to machine coordinate -315.000.
8. Turnning the CNC off and on.
9. Starting correctly on machine coordinate 35.000.
Thus an uncontinuous point of scale data is decided to be between 35.000~45.000.
Edit
Apprv Desig.
5/12
Date
Design
Description
Data
FANUC Series 16i /18i /21i –MA/MB, 18i -MB5
Setting of parameters for rotary scale without
rotar
y data
A-78823E
03 Dec.02.2003 Out of #3 is added.
02 Feb.25.2003
M.tanaka
Out of #2 is altered / added.
Feb.20.2003
Sheet
Title
Draw
No.
Previous page
Next page
