FS 16i/18i/21i-MA/MB, FS 18i-MB5 Additional Manual Page 7
Additional Manual
#7 #6 #5 #4 #3 #2 #1 #0
1817 SCRx
[Data type] Bit axis
SCRx Specifies whether to convert scale data so that rotary axis B type is
available for the axis using a rotary scale without rotary data
0: not to convert
1: to convert
NOTE
・ It is necessary to turn the CNC off after setting this parameter.
・ This parameter is available for only the rotary axis B type.
・ Don’t set this parameter in the case of no uncontinuous point within
movable range of rotary axis even if rotary axis B type.
・ Perform reference position establishment again when this parameter
was changed.
1867 threshold value for converting scale data (all axes)
[Data type] 2 word
[Unit of data]
input increment IS-A IS-B IS-C
unit of data 0.01deg 0.001deg 0.0001deg
[Valid data range] 0～99999999
In the case that scale data is larger than this parameter value, it is converted to be
continuous data in movable range by subtracting one rotary data. The scale data out
of movable range (angle from an uncontinuous point) must be set as threshold value.
This parameter is for all axes. In the case that the parameter for each axis is not 0
this parameter is not available.
NOTE
・ It is necessary to turn the CNC off after setting this parameter.
・ This parameter is available for only the axis with No.1817#3=1.
・ Perform reference position establishment again when this parameter
was changed.
1868 threshold value for converting scale data (each axis)
[Data type] 2 word axis
[Unit of data]
input increment IS-A IS-B IS-C
unit of data 0.01deg 0.001deg 0.0001deg
[valid data range] 0～99999999
In the case that scale data is larger than this parameter value, it is converted to be
continuous data in movable range by subtracting one rotary data. The scale data out
of movable range (angle from an uncontinuous point) must be set as threshold value.
Edit
Apprv Desig.
6/12
Date
Design
Description
Data
FANUC Series 16i /18i /21i –MA/MB, 18i -MB5
Setting of parameters for rotary scale without
rotar
y data
A-78823E
03 Dec.02.2003 Out of #3 is added.
02 Feb.25.2003
M.tanaka
Out of #2 is altered / added.
Feb.20.2003
Sheet
Title
Draw
No.
