FS 16i/18i/21i-MA/MB, FS 18i-MB5 Additional Manual Page 12

Additional Manual
NOTE
Rotary data of RCN223, 723 and 220 can be saved during separate
detector I/F unit turned on. But it is forgotten as soon as it turned off. It
is necessary to set parameters in order to clear rotary data because it
is undefined according to the place where separate detector I/F unit is
turned off. And for this reason, RCN223, 723 and 220 can not be used
for a linear axis.
There is a possibility that the follow-up for rotary axis takes many times
because rotary data can not be cleared if servo software doesn’t
support No.2275#1.
RCN223, 723 can be used even if servo software doesn’t support
No.2275#0. But in this case eight grids are made every one rotation.
(Refer to the part of referece counter capacity setting)
#3
#3
(Other parameters which must be set)
When you use RCN220, the other settings are same as normal α/αi pulse coders.
We show the setting way for RCN223 and RCN723 as follows.
#2
【Flexible feed gear】
No.2084, 2085
flexible feed gear (N/M)
amount of table moving every one rotation of a detector [deg]
increment of detection [deg]
=
8,000,000
In the case of RCN223, 723, amount of pulses every one rotation are regarded as
eight million pulses.
【Amount of positional pulse】
No.2024
amount of positional pulse = 100,000 * (deceleration ratio from a motor to a table)
NOTE) As a result of this equation when amount of pulses exceeds input range (0~
32767), set the positional pulse in following process with using ”positional feed
back pulse conversion coefficient”
amout of positional pulse = A * B
In this case, select B in which A is within 32767. And A, B are set as following.
A : a parameter, amount of positonal pulse (within 32767)
No.2024
B : a parameter, positional feed back pulse conversion coefficient
No.2185
Edit
Apprv Desig.
11/12
Date
Design
Description
Data
FANUC Series 16i /18i /21i –MA/MB, 18i -MB5
Setting of parameters for rotary scale without
rotar
y data
A-78823E
03 Dec.02.2003 Out of #3 is added.
02 Feb.25.2003
M.tanaka
Out of #2 is altered / added.
Feb.20.2003
Sheet
Title
Draw
No.
