9.3.2.5 Details of cable K22

The cable K22 is used to connect the SVM and Pulsecoder.

For servo motor α

αα

αi, α

αα

αis, α

αα

α(HV)i, α

αα

α(HV)is series

and Servo motor β

ββ

βis series (β

ββ

β0.4/5000is to β

ββ

β22/2000is)

(5)

Servo motor

(6)

(9, 20)

(12, 14)

SVM

(7)

*RD

(6)

(5)

(8, 9)

(7, 10)

(4)

(16)

(3)

Drain wire

Ground plate

Shield

20-pin half-pitch connector

Connector (Japan Aviation Electronics Industry)

JN2x S10SL1 : for

5.7 to 7.3 sheath diameter

JN2x S10SL2 : for φ6.5 to 8.0 sheath diameter

D : Straight plug

F : Angle plug

Contact (Japan Aviation Electronics Industry)

JN1-22-22S

Using cable conductor

Signal name Cable length : 28m or less Cable length : 50m or less

5V, 0V, 6V

0.3mm

× 5 (Note 4)

Strand configuration 12/0.18 or 60/0.08

Insulation outer diameter

φ0.8 to φ1.5

0.5mm

× 5 (Note 4)

Strand configuration 20/0.18 or 104/0.08

Insulation outer diameter

φ0.8 to φ1.5

RD, *RD

0.18mm

or more

Twisted-pair wire

Insulation outer diameter

φ0.8 to φ1.5

0.18mm

or more

Twisted-pair wire

Insulation outer diameter

φ0.8 to φ1.5

Drain wire 0.15mm

or more 0.15mm

or more

See Subsection 9.4.1 for explanations about the SVM-side connector

that matches the recommended cable.

See Appendix B, "About Cable Conductors," for detailed

explanations about the cable.
