8. CONNECTION TO SETTING AND DISPLAY UNIT

B–63173EN/03

300

The handy operator’s panel type B allows the Power Mate i to use the

emergency stop feature on the handy operator’s panel as a part of

emergency stop features implemented on a machine tool used with the

CNC.

The specifications of this handy operator’s panel for a machine tool are

the same as the conventional handy operator’s panel (see Section 8.7)

except the following:

D The emergency stop button has two contact outputs.

D Switch A (the conventional deadman’s switch enable switch) can be

used as a modal switch.

D While one of switches B (the conventional deadman’s switches) is

pressed, operations with the handy operator’s panel can be enabled.

D With the conventional handy operator’s panel, when the emergency

stop button is pressed, or the deadman’s switch enable switch is ON,

releasing both the deadman’s switches notifies the Power Mate of the

emergency stop state through communication. With this handy

operator’s panel, the notification of the emergency stop state is not

performed through communication.

D The handy operator’s panel is assumed to be always connected to the

machine.

8.8

CONNECTION TO

THE HANDY

OPERATOR’S PANEL

TYPE B

8.8.1

Overview
