9. SPINDLE FUNCTIONS

B–63502EN/01

NC FUNCTION

Whether to perform constant surface speed control is specified using G96

or G97.

G96 : Constant surface speed control mode

G97 : Constant surface speed control cancel mode

If the surface speed is specified with an S code (S followed by a numeric

value) in the constant surface speed control mode, the spindle speed is

controlled so that a constant surface speed can be maintained while the

tool position is changing.

The axis on which the calculation for constant surface speed control is

based can be specified with either a parameter or the following command:

G96 Pα ; P0 : Axis specified with a parameter

Pα : αth axis (α = 1 to 4)

The specifiable range of the S code is as follows:

1 to 99999 m/min or feet/min

In the constant surface speed control cancel mode, the spindle speed is

specified using an S code.

In the constant surface speed control mode, a constant surface speed

control on signal is output.

By specifying the following command, the maximum spindle speed can

be set:

G92 S_ ; (where, S-- is the maximum spindle speed in rpm)

The spindle speed is clamped when it reaches the specified maximum

spindle speed.

To the spindle speed specified by S, an override from 0% to 254% can be

applied (in steps of 1%).

Actual spindle speed calculated by the return pulses of the position coder

on the spindle is output in 16-bit binary code.

9.5

CONSTANT SURFACE

SPEED CONTROL

9.6

SPINDLE OVERRIDE

9.7

ACTUAL SPINDLE

SPEED OUTPUT

(T series)
