FANUC Series 30i-MODEL A
Live Tool Control With Servo Motor
The relationship between the spindles and functions
Spindle
Function
Spindle Speed
Control
Live Tool Control
With Servo Motor
Threading/feed per revolution
○ ×
Polygon turning
○ ×*1
Spindle speed fluctuation detection
○ ×
Spindle synchronous control
○ ×
Simple spindle synchronous control
○ ×
Polygon turning with two spindles
○ ×
Spindle orientation
Spindle output switching
○ ×
Path spindle control
○ ○
Constant surface speed control
○ ×
Multi spindle control
○ ○
Rigid tapping
○ ○
Spindle output control by the PMC
○ ×
Actual spindle speed output
○ ×
Live tool indexing function
× ○
*1 Possible with a servo motor as a tool rotation axis.
