FANUC Power Mate i-MODEL H

CONNECTION MANUAL(FUNCTION)

Custom Macro in the high response mode

B-63173EN-1/01-27

LimitationsLimitations

 Bracket nesting

Brackets can be used to a depth of one level for every macro statement.

The operation can not be specified between bracket ‘[’ and bracket ‘]’.

Example)

#j = #[#i] •••OK

#j = ABS[#i] •••OK

#j = #[#[#i]] •••NG

#j = ABS[#[#i]] •••NG

#j =#[#i+1] •••NG

Brackets (‘[’ and ‘]’) can not be specified in the conditional expression of

WHILE, IF statements as follows.

Example)

IF [#[#i] EQ 1] GOTO100 •••NG

WHILE [#[#i] EQ 1] DO1 •••NG

 Referring variables

If the variable is specified after F or address word, brackets (‘[’ and ‘]’)

can not be specified.

Example)

G00 X #i •••OK

G00 X #[#i] •••NG

The variables can not be referred as the number after GOTO, DO and

END.

Example)

GOTO#i •••NG

IF [.....] GOTO #i •••NG

WHILE [...] DO#i •••NG

END#i •••NG

 Number of the terms for the operation

The number of the terms for the operation is up to two per a block. The

operation can not be specified for a conditional expression of WHILE

statement or IF statement. The operation can not be specified for the

block that the ABS operation is specified.

Example)

#i = #i + #j •••OK

#i = #i ∗ #j •••OK

#i = #i ∗ #j / #k •••NG

IF [#i EQ #i +1] GOTO100 •••NG

WHILE [#i EQ #i +1] DO1 •••NG

#i = ABS[#i] •••OK

#i = ABS[#i + #j] •••NG

#i = ABS[#i] + ABS[#j] •••NG
