Series 16i/18i/160i/180i - TB Operators manual Page 396

Operators manual
PROGRAMMING
18. FUNCTIONS FOR HIGH SPEED
CUTTING
B–63524EN/01
370
Function name Applicability
Additional registered programs A (125 programs) f
Additional registered programs B (200 programs) f
Additional registered programs C (400 programs) f
Additional registered programs D (1000 programs) f
Additional optional block skip f
Background editing f
Expanded tape editing f
Software operator’s panel f
General switches of software operator’s panel f
Machining time stamp f
Japanese–language display f
German/French–language display f
Chinese–language display f
Italian–language display f
Korean–language display f
Spanish–language display f
Display of run time and parts count f
Graphic display f
Floppy Cassette directory display f
Feed per revolution f
Skip function (G31) Y
Low–speed reference position return (G28) Y
Torque limit skip Y
Threading Y
<Applicability>
f : The function can be used in the look–ahead control mode.
Y : The function cannot be used in the look–ahead control mode.
When using the function, cancel the look–ahead control mode.
NOTE
1 PMC axis control can be enabled only for advance feed
forward.
2 Cs contour control can be performed in the look–ahead
control mode if the G8S bit (bit 5 of parameter 1602) is set
accordingly.
