APPENDIX

B–63524EN/01

G. ALARM LIST

875

No. DescriptionFaulty location and remedy

SPM in-

dica-

tion(*1)

Message

7n97 SPN_n_ : OTHER

SPINDLE

ALARM

97 Replace the SPM. Another irregularity was detected.

7n98 SPN_n_ : OTHER CON-

VERTER

ALARM

98 Check the PSM alarm display. A PSM alarm was detected.

No. Message

SPM in-

dica-

tion(*1)

Faulty location and remedy Description

9n01 SPN_n_ : MOTOR OVER-

HEAT

01 1 Check and correct the peripheral

temperature and load status.

2 If the cooling fan stops, replace it.

The thermostat embedded in the mo-

tor winding operated.

The internal temperature of the motor

exceeds the specified level.

The motor is used in excess of the

continuous rating, or the cooling com-

ponent is abnormal.

9n02 SPN_n_ : EX SPEED ER-

ROR

02 1 Check and correct the cutting

conditions to decrease the load.

2 Correct parameter No. 4082.

The motor speed cannot follow a spe-

cified speed.

An excessive motor load torque is de-

tected.

The acceleration/deceleration time in

parameter No. 4082 is insufficient.

9n03 SPN_n_ : FUSE ON DC

LINK BLOWN

03 1 Replace the SPM unit.

2 Check the motor insulation status.

3 Replace the interface cable.

The PSM becomes ready (00 is indi-

cated), but the DC link voltage is too

low in the SPM.

The fuse in the DC link section in the

SPM is blown. (The power device is

damaged or the motor is ground–

fault.)

The JX1A/JX1B connection cable is

abnormal.

9n06 06 1 Check and correct the parameter.

2 Replace the feedback cable.

The temperature sensor of the motor

is disconnected.

9n07 SPN_n_ : OVERSPEED 07 Check for a sequence error. (For ex-

ample, check whether spindle syn-

chronization was specified when the

spindle could not be turned.)

The motor speed has exceeded

115% of its rated speed.

When the spindle axis was in position

control mode, positional deviations

were accumulated excessively (SFR

and SRV were turned off during

spindle synchronization.)

9n09 SPN_n_ : OVERHEAT

MAIN CIRCUIT

09 1 Improve the heat sink cooling sta-

tus.

2 If the heat sink cooling fan stops,

replace the SPM unit.

Abnormal temperature rise of the

power transistor radiator
