Series 16i/18i/160i/180i - TB Operators manual Page 672

Operators manual
8. DATA INPUT/OUTPUT
B–63524EN/01
OPERATION
646
Deleting a file
1 Press the EDIT switch on the machine operator’s panel.
2 Press function key
PROG
.
3 Press the rightmost soft key (next–menu key).
4 Press soft key [CARD]. The screen shown below is displayed.
PROG (OPRT)DIR +
DIRECTORY (M–CARD)
No. FILE NAME SIZE DATE
O0034 N00045
0001 O1000 123456 96/07/10
0002 O1001 118458 96/07/30
0003 O0002 113250 96/07/30
0004 O2000 173456 96/07/31
0005 O2001 113444 96/07/31
0006 O3001 118483 96/08/02
0007 O3300 111406 96/08/05
0008 O3400 112420 96/07/31
0009 O3500 117460 96/07/31
~ ~
5 Press soft key [(OPRT)].
6 Set the number of the desired file with soft key [DELETE], then press
soft key [EXEC]. The file is deleted, and the directory screen is
displayed again.
When file number 21 is deleted
DIRECTORY (M–CARD)
No. FILE NAME COMMENT
O0034 N00045
0019 O1000 (MAIN PROGRAM)
0020 O1010 (SUBPROGRAM–1)
0021 O1020 (COMMENT )
0022 O1030 (COMMENT )
~ ~
File name O1020 is deleted.
DIRECTORY (M–CARD)
No. FILE NAME COMMENT
O0034 N00045
0019 O1000 (MAIN PROGRAM)
0020 O1010 (SUBPROGRAM–1)
0021 O1020 (COMMENT )
0022 O1030 (COMMENT )
~ ~
File number 21 is assigned to the next file name.
Procedure
DELETE
PUNCH
F SRH
F READ N READ
