4. AUTOMATIC OPERATION
523
Procedure for Program Restart by Specifying a Block Number
1 Retract the tool and replace it with a new one. When necessary,
change the offset. (Go to step 2.)
1 When power is turned ON or emergency stop is released, perform all
necessary operations at that time, including the reference position
return.
2 Move the machine manually to the program starting point (machining
start point), and keep the modal data and coordinate system in the
same conditions as at the machining start.
3 If necessary, modify the offset amount.
1 Turn the program restart switch on the machine operator’s panel ON.
2 Press function
PROG
key to display the desired program.
3 Find the program head. Press function
RESET
key.
4 Enter the number of the block to be restarted then press the
[P TYPE]
or [Q TYPE] soft key. The block number cannot exceed eight digits.
5 The block number is searched for, and the program restart screen
appears on the display.
PROGRAM RESTART
DESTINATION
X 57. 096
Z 56. 943
DISTANCE TO GO
1 X 1. 459
2 Z 7. 320
M 1 2
1 2
1 2
1 2
1 2
1 * * * * * * * *
* * * * * * * ** * * * * * * *
T* * * * * * * ** * * * * * * *
S * * * * *
O0002 N01000
S 0 T0000
MEM
* * * * * * * * * *
10 : 10 : 40
FL.SDL
(OPRT)
RSTR
BC : 00000002
DESTINATION shows the position at which machining is to restart.
DISTANCE TO GO shows the distance from the current tool position
to the position where machining is to restart. A number to the left of
each axis name indicates the order of axes (determined by parameter
setting) along which the tool moves to the restart position.
Procedure 1
[ P TYPE ]
[ Q TYPE ]
Procedure 2
[COMMON TO P TYPE /
Q TYPE]
B
f f f f f f f f
Block number
[P TYPE]
or
[Q TYPE]
Previous page
Next page
