Bit 0 (JAXx) of
parameter No. 7010
OPERATION3.MANUAL OPERATION
B–63524EN/01
504
The manual numeric command function allows data programmed
through the MDI to be executed in jog mode. Whenever the system is
ready for jog feed, a manual numeric command can be executed. The
following eight functions are supported:
(1)Positioning (G00)
(2)Linear interpolation (G01)
(3)Automatic reference position return (G28)
(4)2nd/3rd/4th reference position return (G30)
(5)M codes (miscellaneous functions)
(6)S codes (spindle functions)
(7)B codes (second auxiliary functions)
By setting the following parameters, the commands for axial motion and
the M, S, T, and B functions can be disabled:
(1)Positioning (G00)
(2)Linear interpolation (G01):
(3)Automatic reference position
return (G28):
(4)2nd/3rd/4th reference position
return (G30):
(5)M codes (miscellaneous functions):
Bit 0 (JMF) of parameter No. 7002
(6)S codes (spindle functions):
Bit 1 (JSF) of parameter No. 7002
(7)B codes (second auxiliary functions):
Bit 3 (JBF) of parameter No. 7002
Procedure Manual numeric command
1 Press the jog switch (one of the mode selection switches).
2 Press function key
PROG
.
3 Press soft key [JOG] on the screen. The following manual numeric
command screen is displayed.
3.7
MANUAL NUMERIC
COMMAND
Procedure
REMOTE
MDI
MEMORY
EDIT
ZERO
RETURN
TEACH
JOG
MODE
HANDLE
Previous page
Next page
