0i - PC Connection manual (Function) Page 13

Connection manual (Function)
B–64153EN/01
1. LIST OF FUNCTIONS
1
1
LIST OF FUNCTIONS
For details of connections that are not related to the punch press function,
refer to the “FANUC Series 0i–MODEL B CONNECTION MANUAL
(FUNCTION)” (B–64113EN–1). Most of the functions described in
B–64113EN–1 can be used with the FANUC Series 0i–PC. The
remainder either cannot be used with the FANUC Series 0i–PC or have
different specifications when used with the FANUC Series 0i–PC. The
table below indicates whether the functions described in B–64113EN–1
can be used with the FANUC Series 0i–PC. For an explanation of the
differences in the specifications, see Chapter 2.
The table below lists the functions.
The following symbols are used in the table:
f : The function can be used with the FANUC Series
0i–PC.
× : The function cannot be used with the FANUC Series
0i–PC.
∆ : The function has different specifications when used with the
FANUC Series 0i–PC.
No. Item
Whether
supported
1 Axis control
1.1 Number of Controlled axes f
1.2 Setting each axis
Name of axes ∆: See chapter 2
Increment system ∆: See chapter 2
Specifying the rotation axis ∆: See chapter 2
Outputting the movement state of an axis f
Mirror image ∆: See chapter 2
Follow–up ∆: See chapter 2
Servo off (mechanical handle) f
Position switch f
1.3 Error compensation
Stored pitch error compensation f
Backlash compensation f
Bi–directional pitch error compensation f
1.4 Settings related to servo–controlled axes
General
