0i - PC Connection manual (Function) Page 138

Connection manual (Function)
A. CNC AND PMC INTERFACE
B–64153EN/01
APPENDIX
126
Group
Reference
item
AddressNameSymbol
R
RP1T–RP16T T–axis machine zero point position signals F244–F245 5.3.6
RSTSW Reset key signal F239#5 8.2
RTCOV0–RTCOV6 Rapid traverse time constant override signals G241#0–#6 8.3
S
SAFEXE Safety zone setting ready signal F231#6 7.2
SAFRQ Automatic safety zone setting request signal G232#5 7.5.2
SAFZ Workpiece holder position detector signal X004#1 7.5
SKIP Skip signal X004#0 2.11.1
SNP Two–step selection for nibbling signal G230#6 3.6.9
SPRL Feed hold lamp signal B F230#4 8.1
SZT1–SZT12 In safety zone signal F240–F241#0–#3 7.6
SZTS0–SZTS3 Selection signal for tool area of safety zone G232#0–#3 7.6
T
TCNG Tool change signal G233#6 5.3.2
TI00–TI31 T code display signal G234–G237 5.3.4
TIE Turret indexing completion signal F232#6 5.3.3
TNG T command neglect signal G233#5 5.3.1
W
WDC Punch enable signal G232#4 7.2
WDDO Punch forbidden area entered signal F231#7 7.2
