0i - PC Connection manual (Function) Page 143

Connection manual (Function)
B–64153EN/01
B. ALARM LISTAPPENDIX
131
Number ContentsMessage
4700 PROGRAM ERROR (OT +) The value specified in the X–axis move command exceeded the posi-
tive value of stored stroke limit 1. (Advance check)
4701 PROGRAM ERROR (OT –) The value specified in the X–axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
4702 PROGRAM ERROR (OT +) The value specified in the Y–axis move command exceeded the posi-
tive value of stored stroke limit 1. (Advance check)
4703 PROGRAM ERROR (OT –) The value specified in the Y–axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
4704 PROGRAM ERROR (OT +) The value specified in the Z–axis move command exceeded the posi-
tive value of stored stroke limit 1. (Advance check)
4705 PROGRAM ERROR (OT –) The value specified in the Z–axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
2) Safety zone alarms
Number Message Contents
4800 ZONE : PUNCHING INHIBITED 1 When a safety zone check was executed, a punch command was
specified in area 1 where punching is inhibited.
4801 ZONE : PUNCHING INHIBITED 2 When a safety zone check was executed, a punch command was
specified in area 2 where punching is inhibited.
4802 ZONE : PUNCHING INHIBITED 3 When a safety zone check was executed, a punch command was
specified in area 3 where punching is inhibited.
4803 ZONE : PUNCHING INHIBITED 4 When a safety zone check was executed, a punch command was
specified in area 4 where punching is inhibited.
4810 ZONE : ENTERING INHIBITED 1 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 1 into which entry is inhibited.
4811 ZONE : ENTERING INHIBITED 1
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 1 into which entry is inhibited.
4812 ZONE : ENTERING INHIBITED 2 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 2 into which entry is inhibited.
4813 ZONE : ENTERING INHIBITED 2
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 2 into which entry is inhibited.
4814 ZONE : ENTERING INHIBITED 3 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 3 into which entry is inhibited.
4815 ZONE : ENTERING INHIBITED 3
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 3 into which entry is inhibited.
4816 ZONE : ENTERING INHIBITED 4 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 4 into which entry is inhibited.
4817 ZONE : ENTERING INHIBITED 4
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 4 into which entry is inhibited.
4830 ZONE : ENTERING INHIBITED 1 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 1 into which entry is inhibited.
